Process Connection Tri-Clover
- ½” to 4”
Instrument Thread
- ½”BSP
- ½”NPT
Insertion length
- 20 … 3000 mm
Well tube Diameter
- Standard 10mm diameter 7mm internal diameter
- 12mm diameter 9mm internal diameter
- Customisable upon request
Well tube material
- AISI 316L (1.4404)
Surface roughness wetted parts
- Ra ≤ 0.4 µm
Performance characteristics
Max. flow velocity
- See Datasheet
Thermal response time
- See datasheet
Certification Options
- See 3.1b Material Cert
- Surface Finish Cert
